- 商品名稱：銅帶繞包屏蔽電纜 ZA-NA-KVVRP2 耐火控制軟電纜
- 添加時間：2021-12-01 20:48:03
- 推薦度：
介紹：
產品型號：ZA-NA-KVVRP2
產品簡稱：耐火控制電纜
導體材料：無氧銅絲
J緣材料：阻燃聚氯乙烯J緣
屏蔽材料：銅帶繞包屏蔽
護套材料：阻燃聚氯乙烯護套
結 構：絞合型
加 強 件：云母繞包
鎧裝材料：/
芯線顏色：5芯以內顏色區分，5芯以上黑色線體白色數字編號
阻 燃 性：符合IEC 60332
工作電壓：1/35kV
出廠測試電壓：2000V-3000V
zui小彎曲半徑：電纜外徑*8倍
長期工作溫度應不高于+105℃
長期工作溫度應不低于-10℃
可彎曲性、耐潮濕、耐寒、耐油
能承受中等的機械應力
具有較強的抗電磁干擾能力
環保型號：WDZ-KVVRP2
耐火型號：NH-KVVRP2
阻燃型號：ZR-KVVRP2
本安型號：IA-KVVRP2
| ZA-NA-KVVRP2 銅芯阻燃聚氯乙烯J緣和護套銅帶繞包屏蔽耐火控制軟電纜 | |||||
| 型號 | 規格 | 規格 | 工作電壓 | 工作溫度 | 彎曲半徑 |
| ZA-NA-KVVRP2 | 2*0.5 | 12*0.75 | 450/750V | ℃ +105-10 | 外徑10倍 |
| ZA-NA-KVVRP2 | 2*0.75 | 12*1.0 | 450/750V | ℃ +105-10 | 外徑10倍 |
| ZA-NA-KVVRP2 | 2*1.0 | 12*1.5 | 450/750V | ℃ +105-10 | 外徑10倍 |
| ZA-NA-KVVRP2 | 2*1.5 | 12*2.5 | 450/750V | ℃ +105-10 | 外徑10倍 |
| ZA-NA-KVVRP2 | 2*2.5 | 12*4 | 450/750V | ℃ +105-10 | 外徑10倍 |
| ZA-NA-KVVRP2 | 2*4 | 12*6 | 450/750V | ℃ +105-10 | 外徑10倍 |
| ZA-NA-KVVRP2 | 2*6 | 14*0.5 | 450/750V | ℃ +105-10 | 外徑10倍 |
| ZA-NA-KVVRP2 | 2*10 | 14*0.75 | 450/750V | ℃ +105-10 | 外徑10倍 |
| ZA-NA-KVVRP2 | 3*0.5 | 14*1.0 | 450/750V | ℃ +105-10 | 外徑10倍 |
| ZA-NA-KVVRP2 | 3*0.75 | 14*1.5 | 450/750V | ℃ +105-10 | 外徑10倍 |
| ZA-NA-KVVRP2 | 3*1.0 | 14*2.5 | 450/750V | ℃ +105-10 | 外徑10倍 |
| ZA-NA-KVVRP2 | 3*1.5 | 14*4 | 450/750V | ℃ +105-10 | 外徑10倍 |
| ZA-NA-KVVRP2 | 3*2.5 | 14*6 | 450/750V | ℃ +105-10 | 外徑10倍 |
| ZA-NA-KVVRP2 | 3*4 | 16*0.5 | 450/750V | ℃ +105-10 | 外徑10倍 |
| ZA-NA-KVVRP2 | 3*6 | 16*0.75 | 450/750V | ℃ +105-10 | 外徑10倍 |
| ZA-NA-KVVRP2 | 3*10 | 16*1.0 | 450/750V | ℃ +105-10 | 外徑10倍 |
| ZA-NA-KVVRP2 | 4*0.5 | 16*1.5 | 450/750V | ℃ +105-10 | 外徑10倍 |
| ZA-NA-KVVRP2 | 4*0.75 | 16*2.5 | 450/750V | ℃ +105-10 | 外徑10倍 |
| ZA-NA-KVVRP2 | 4*1.0 | 19*0.5 | 450/750V | ℃ +105-10 | 外徑10倍 |
| ZA-NA-KVVRP2 | 4*1.5 | 19*0.75 | 450/750V | ℃ +105-10 | 外徑10倍 |
| ZA-NA-KVVRP2 | 4*2.5 | 19*1.0 | 450/750V | ℃ +105-10 | 外徑10倍 |
| ZA-NA-KVVRP2 | 4*4 | 19*1.5 | 450/750V | ℃ +105-10 | 外徑10倍 |
| ZA-NA-KVVRP2 | 4*6 | 19*2.5 | 450/750V | ℃ +105-10 | 外徑10倍 |
| ZA-NA-KVVRP2 | 4*10 | 24*0.5 | 450/750V | ℃ +105-10 | 外徑10倍 |
| ZA-NA-KVVRP2 | 5*0.5 | 24*0.75 | 450/750V | ℃ +105-10 | 外徑10倍 |
| ZA-NA-KVVRP2 | 5*0.75 | 24*1.0 | 450/750V | ℃ +105-10 | 外徑10倍 |
| ZA-NA-KVVRP2 | 5*1.0 | 24*1.5 | 450/750V | ℃ +105-10 | 外徑10倍 |
| ZA-NA-KVVRP2 | 5*1.5 | 24*2.5 | 450/750V | ℃ +105-10 | 外徑10倍 |
| ZA-NA-KVVRP2 | 5*2.5 | 27*0.5 | 450/750V | ℃ +105-10 | 外徑10倍 |
| ZA-NA-KVVRP2 | 5*4 | 27*0.75 | 450/750V | ℃ +105-10 | 外徑10倍 |
| ZA-NA-KVVRP2 | 5*6 | 27*1.0 | 450/750V | ℃ +105-10 | 外徑10倍 |
| ZA-NA-KVVRP2 | 5*10 | 27*1.5 | 450/750V | ℃ +105-10 | 外徑10倍 |
| ZA-NA-KVVRP2 | 6*0.5 | 27*2.5 | 450/750V | ℃ +105-10 | 外徑10倍 |
| ZA-NA-KVVRP2 | 6*0.75 | 30*0.5 | 450/750V | ℃ +105-10 | 外徑10倍 |
| ZA-NA-KVVRP2 | 6*1.0 | 30*0.75 | 450/750V | ℃ +105-10 | 外徑10倍 |
| ZA-NA-KVVRP2 | 6*1.5 | 30*1.0 | 450/750V | ℃ +105-10 | 外徑10倍 |
| ZA-NA-KVVRP2 | 6*2.5 | 30*1.5 | 450/750V | ℃ +105-10 | 外徑10倍 |
| ZA-NA-KVVRP2 | 6*4 | 30*2.5 | 450/750V | ℃ +105-10 | 外徑10倍 |
| ZA-NA-KVVRP2 | 6*6 | 37*0.5 | 450/750V | ℃ +105-10 | 外徑10倍 |
| ZA-NA-KVVRP2 | 6*10 | 37*0.75 | 450/750V | ℃ +105-10 | 外徑10倍 |
| ZA-NA-KVVRP2 | 7*0.5 | 37*1.0 | 450/750V | ℃ +105-10 | 外徑10倍 |
| ZA-NA-KVVRP2 | 7*0.75 | 37*1.5 | 450/750V | ℃ +105-10 | 外徑10倍 |
| ZA-NA-KVVRP2 | 7*1.0 | 37*2.5 | 450/750V | ℃ +105-10 | 外徑10倍 |
| ZA-NA-KVVRP2 | 7*1.5 | 44*0.5 | 450/750V | ℃ +105-10 | 外徑10倍 |
| ZA-NA-KVVRP2 | 7*2.5 | 44*0.75 | 450/750V | ℃ +105-10 | 外徑10倍 |
| ZA-NA-KVVRP2 | 7*4 | 44*1.0 | 450/750V | ℃ +105-10 | 外徑10倍 |
| ZA-NA-KVVRP2 | 7*6 | 44*1.5 | 450/750V | ℃ +105-10 | 外徑10倍 |
| ZA-NA-KVVRP2 | 8*0.5 | 44*2.5 | 450/750V | ℃ +105-10 | 外徑10倍 |
| ZA-NA-KVVRP2 | 8*0.75 | 48*0.5 | 450/750V | ℃ +105-10 | 外徑10倍 |
| ZA-NA-KVVRP2 | 8*1.0 | 48*0.75 | 450/750V | ℃ +105-10 | 外徑10倍 |
| ZA-NA-KVVRP2 | 8*1.5 | 48*1 | 450/750V | ℃ +105-10 | 外徑10倍 |
| ZA-NA-KVVRP2 | 8*2.5 | 48*1.5 | 450/750V | ℃ +105-10 | 外徑10倍 |
| ZA-NA-KVVRP2 | 8*4 | 48*2.5 | 450/750V | ℃ +105-10 | 外徑10倍 |
| ZA-NA-KVVRP2 | 8*6 | 52*0.5 | 450/750V | ℃ +105-10 | 外徑10倍 |
| ZA-NA-KVVRP2 | 10*0.5 | 52*0.75 | 450/750V | ℃ +105-10 | 外徑10倍 |
| ZA-NA-KVVRP2 | 10*0.75 | 52*1.0 | 450/750V | ℃ +105-10 | 外徑10倍 |
| ZA-NA-KVVRP2 | 10*1.0 | 52*1.5 | 450/750V | ℃ +105-10 | 外徑10倍 |
| ZA-NA-KVVRP2 | 10*1.5 | 52*2.5 | 450/750V | ℃ +105-10 | 外徑10倍 |
| ZA-NA-KVVRP2 | 10*2.5 | 61*0.5 | 450/750V | ℃ +105-10 | 外徑10倍 |
| ZA-NA-KVVRP2 | 10*4 | 61*0.75 | 450/750V | ℃ +105-10 | 外徑10倍 |
| ZA-NA-KVVRP2 | 10*6 | 61*1.0 | 450/750V | ℃ +105-10 | 外徑10倍 |
| ZA-NA-KVVRP2 | 12*0.5 | 61*1.5 | 450/750V | ℃ +105-10 | 外徑10倍 |
